| Weaving workshop | |||
 |  |
 |  |
| Resin production line | Resin coating production line | Release paper production line | Weaving yarn |
| Material preparation workshop | |||
 |  |
 |  |
| In 2017, in order to meet the trend of lightweight products, more than 20 CNC infrared cutting machines were added, which can cut the material as a whole according to the product shape. When the material is coiled, the product has less overlap and stable strength, which lays the foundation for the development of lightweight products. At present, lightweight products can be controlled below 650g. | |||
| Coil workshop | |||
 |  |
 |  |
| In 2018, EPS imported coil material replaced the original core mold coil material method, breaking through the technical bottleneck of carbon fiber coil material. The coil material has a supporting point, and the appearance texture directly replaces the mold, reducing the distortion of the appearance texture and reducing the wind. And the product was scrapped due to air leakage, and the qualified rate after molding increased by 38.5%. | |||
| Molding workshop | |||
 |  |
 |  |
| The original PTF molding process, the product has high technical content, superior performance, and low cost, which fills the gap in this field in China and ranks among the best in the domestic industry. The technical achievement appraisal conclusion is that "the product performance has reached the international advanced level, and the carbon fiber composite material molding process and application are at the domestic leading level". | |||
| Fine plus CNC workshop | |||
 |  |
 |  |
| Equipped with modern finishing technology and more than 70 finishing CNC machines, it lays a quality foundation for product finishing. The product quality is far ahead in the industry. In 2012, it was awarded the "China Quality Integrity Enterprise" by the China Outbound Inspection and Quarantine Association. . | |||
| Gluing workshop | |||
 |  |
 |  |
| The CNC integrated tail trimming imitation pin replaces the original manual imitation pin and tail trimming. When the product is glued, the assembly dimensional tolerance is more precise, and the quality after gluing is more stable. Avoid the hidden danger of strength due to imitation sales deviation. | |||
| Repair workshop | |||
 |  |
 |  |
| Fork repairing | Fork repairing | Frame repairing | Frame repairing |
| Paint workshop | |||
 |  |
 |  |
| High-tech, dust-free, fully automatic paint spray booths make use of the directional nature of the pressure to spray paint vertically from above and below, making spraying more accurate. In terms of hardware, there is a mainframe room with "multi-layer filtering cotton" instead of filtering cloth, resulting in high air cleanliness and a low chance of rework, saving paint and improving work efficiency. | |||
